| Rated Voltage: | 12V | Nominal Capacity: | 100Ah |
|---|---|---|---|
| Dimensions (L×W×H): | 330±2mm × 173±2mm × 212±2mm (13.0×6.81×8.35 inches) | Total Height (incl. terminals): | 220±2mm (8.66 inches) |
| Weight: | 30.5kg (67.2 lbs) | Terminal Type: | M8 |
| Container Material: | ABS | Extended Service Life: | 12-year floating life at 25°C |
ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems
ESTEL DJM12100 is a robust 12V 100Ah general-purpose lead-acid battery designed for demanding applications requiring reliable long-term power. With its high-capacity design and superior discharge performance, this battery delivers consistent energy for critical systems. Featuring a durable ABS container and advanced safety technology, it offers up to 12 years of floating service life at 25°C. Certified to international standards, it is ideal for telecommunications, data centers, renewable energy storage, and industrial applications.
| Discharge Rate | Capacity | Current |
| C20 | 105.0 Ah | 5.25A |
| C10 | 100.0 Ah | 10.0A |
| C5 | 84.5 Ah | 16.9A |
| C3 | 77.1 Ah | 25.7A |
| C1 | 58.1 Ah | 58.1A |
≤3% per month at 25°C
| FinalVoltage | 5min | 10min | 30min | 1h | 5h | 10h | 20h |
| 1.85V/cell | 197.7 | 140.5 | 78.8 | 50.9 | 15.8 | 9.55 | 5.07 |
| 1.80V/cell | 224.8 | 159.5 | 85.8 | 52.7 | 16.6 | 10.0 | 5.25 |
| 1.60V/cell | 279.7 | 196.8 | 92.0 | 58.1 | 17.8 | 10.5 | 5.49 |
| Final Voltage | 5min | 10min | 30min | 1h | 5h | 10h | 20h |
| 1.85V/cell | 369.1 | 264.4 | 150.7 | 98.5 | 31.1 | 19.0 | 10.1 |
| 1.80V/cel | 412.9 | 295.8 | 162.7 | 101.4 | 32.6 | 19.9 | 10.4 |
